| Electric motor rated output kW｛PS｝ | 0.75｛1｝ |
|---|---|
| Control pressure MPa（kgf/cm2） | 0.8-1.0 |
| Output air volume L/min | 75 |
| Air tank capacity L | 50 |
| Air outtake B | G1/4×1 Ball valve male screw |
| External dimensions (W x D x H)mm | 800×375×705 |
| Mass kg | Three-phase 52 Single-phase 56 |
| Noise level (1.5m in front) dB(A) | 71 |
| Operating control method | Pressure switch |
| Voltage V | Single-phase 100V Three-phase 200V |
